EPIC HT:
You’ve seen the look. The, are-they-really-about-to-ride-that-on-a-hardtail look. Well, get ready to get it a lot more aboard the Epic Hardtail. Fast and light meets confident and capable in a bike that’s been bred to redefine what’s possible on a cross-country speed demon.
- Ridiculously capable, incredibly light, and refreshingly comfortable, the Epic Hardtail’s dropper-post friendly FACT 11m carbon frame rewrites the hardtail playbook with game-changing success.
- Don't judge this Judy without being prepared to come away impressed. RockShox's capable Motion Control Damper and Solo Air spring combine for composed, predictable travel and effortless setup and adjustment.
- SRAM's Level T hydraulic disc brakes pack a punch, offering serious bite and backing it up with a refined, intuitive feel to make for a package that squeezes heavyweight performance out of a scale-friendly setup.
Technical Specifications
FRAMESET
Frame
Specialized FACT 11m, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing
Seat Binder
Specialized Alloy, 34.9mm
Suspension
Fork
RockShox Judy Gold, Motion Control damper, Solo Air, 42mm offset, 15x110mm thru-axle, 100mm of travel (XS - 80mm travel)
COCKPIT
Stem
3D-forged alloy, 31.8mm, 7-degree
Handlebars
Specialized Alloy XC minirise, double-butted alloy, 8-degree backsweep, 6-degree upsweep, 10mm rise, 31.8mm
Tape
Specialized Trail Grips
Saddle
Body Geometry Power Sport, steel rails
SeatPost
Specialized Alloy, Single Bolt, 30.9mm
BRAKES
Front Brake
SRAM Level T hydraulic disc, 2-Piston Caliper
Rear Brake
SRAM Level T hydraulic disc, 2-Piston Caliper
DRIVETRAIN
Rear Derailleur
SRAM NX Eagle, 12-speed
Shift Levers
SRAM NX Eagle, trigger, 12-speed
Cassette
SRAM NX Eagle, 12-speed, 11-50t
Chain
SRAM SX Eagle, 12-speed w/ PowerLock®
Crankset
SRAM X1000 Eagle, DUB, 170/175mm 32T
Chainrings
32T
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
WHEELS
Rims
Specialized Alloy, Tubeless Ready, 25mm internal width, 28h
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
Front Tire
Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35
Rear Tire
Specialized Renegade, Control Casing, T5 Compound, 29x2.35
Inner Tubes
Standard, Presta valve
WHEELS & TIRES
Spokes
Stainless, 14g
Geometry
XS | S | M | L | XL | |
---|---|---|---|---|---|
Crank Length | 165mmm | 170mm | 175mm | 175mm | 175mm |
Stem Length | 60mm | 60mm | 70mm | 70mm | 70mm |
Handlebar Width | 750mm | 750mm | 750mm | 750mm | 750mm |
Seatpost Length | 350mm | 350mm | 400mm | 400mm | 400mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
Stack | 594mm | 608mm | 608mm | 622mm | 636mm |
Reach | 385mm | 405mm | 430mm | 455mm | 480mm |
Head Tube Length | 95mm | 95mm | 95mm | 110mm | 125mm |
Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
BB Height | 309mm | 309mm | 309mm | 309mm | 309mm |
BB Drop | 63mm | 63mm | 63mm | 63mm | 63mm |
Trail | 103mm | 103mm | 103mm | 103mm | 103mm |
Fork Length, Full | 486mm | 506mm | 506mm | 506mm | 506mm |
Fork Rake/Offset | 42mm | 42mm | 42mm | 42mm | 42mm |
Front Center | 641mm | 668mm | 693mm | 723mm | 753mm |
Chainstay Length | 430mm | 430mm | 430mm | 430mm | 430mm |
Wheelbase | 1062mm | 1090mm | 1115mm | 1146mm | 1176mm |
Top Tube Length, Horizontal | 555mm | 579mm | 604mm | 633mm | 662mm |
Bike Standover Height | 732mm | 762mm | 792mm | 816mm | 847mm |
Seat Tube Length | 367mm | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 74° | 74° | 74° | 74° | 74° |
